Spiral Plate Heat Exchanger
Spiral Plate
Heat Exchanger
This spiral plate heat exchanger provides efficient and stable heat transfer through a compact single-channel structure, making it ideal for viscous, fouling, and particle-containing fluids.
| HX-P-31-Spiral Plate Heat Exchanger – Product Specifications | |
|---|---|
| Plate Materials | Carbon Steel (Q235 / Q345), SS304, SS316L, 904L, Duplex Stainless Steel 2205, Titanium, C276 (customizable) |
| Plate Thickness | 2.0 mm / 2.5 mm / 3.0 mm / 4.0 mm |
| Gasket Materials | NBR, EPDM, FKM (Viton), PTFE, graphite composite |
| Gasket Structure | Fully welded sealing structure; flange face sealing; optional double sealing structure |
| Frame Materials | Carbon steel (anti-corrosion coating), stainless steel, epoxy resin anti-corrosion treatment |
| Nozzles | Welded nozzles in carbon steel or stainless steel; optional wear-resistant liner |
| Connection Size | DN50 – DN600 |
| Connection Standard | Customized |
| Color Customization | Customized |
| Applications | Chemical processes, high-viscosity media, particle-containing fluids, wastewater and waste heat recovery, pharmaceutical, metallurgy, papermaking |
Important Attributes
| Item | Content |
|---|---|
| Material | Stainless Steel |
| Key Advantages | Long service life |
| Voltage | 220V / 380V / 480V or customized |
| Structure | Plate Heat Exchanger |
| Core Components | PLC, pressure vessel, pump |
| Mechanical Test Report | Available |
| Video Factory Inspection | Available |
| Fluid Flow Velocity | 1.5 m/s |
| Maximum Working Pressure | 2.5 MPa |
| Plate Materials | SS304, SS316, 904L, 254SMO, C276, Titanium, Nickel, Incoloy 825 |
| Plate Thickness | 0.5 mm, 0.6 mm, 0.8 mm, 1.0 mm |
| Gasket Materials | NBR, HNBR, EPDM, HEPDM, FKM (Viton), CR |
| Gasket Assembly Type | Clamped, locked, snap-on, bonded |
| Frame Materials | Carbon steel, stainless steel, stainless steel cladding |
| Nozzle Type | Flanged, rubber insert, metal insert, threaded, clamp |
| Connection Size | DN15 – DN500 |
| Certification | ISO 9001 |
Applications
The spiral plate heat exchanger is suitable for a wide range of heat transfer duties, including:
Liquid-to-Liquid heat exchange
Gas-to-Liquid heat exchange
Gas-to-Gas convective heat transfer
Steam Condensation
Liquid Evaporation
It is widely used in
- Chemical and petrochemical industries
- Pharmaceutical processing
- Food and beverage production
- Pulp and paper industry
- Environmental protection and wastewater treatment
Built on Capability
Not Claims
Compact &
Space-Saving
Small size with high heat transfer area per unit volume.
High Heat
Transfer Efficiency
True counter-flow design enhances thermal performance.
Reduced Metal Consumption
Uniform temperature distribution reduces stress and extends.
Low Thermal Stress
Continuous spiral channels without dead zones help prevent.
Self-Cleaning Effect
Optimized plate design lowers material usage.
Easy Maintenance
Optional removable end covers allow convenient inspection and cleaning.
